YV88-X YAMAHA SMT used machine,chip mounter

Yamaha YV100X is a mid-speed multi-function placement machine to adapt to medium-speed

small-sized components and high-precision mounting of shaped components, using the latest

Yamaha latest closed-loop technology, dual drive technology. Used Yamaha YV100X placement

machine factory period 1999-2004 years; YV100XE general year: 2004-2006, DOS operating

system, a working head, 8 nozzles, 2 high-resolution multi-vision digital camera, Optional with

YAMAHA patented flight for the first move, from 0201 (British) micro-components to 32mm

chip SMD components, including IC.QFP.SOT.SOP.SOJ.PLCC.BGA. Heterosexual components

such as connectors can be mounted . Mechanical structure is simple, a casting frame made to

ensure durability and stability, the circuit control department is not complicated, easy maintenance.

Menu is relatively simple, easy to operate, can be easily modified stickers 1.2 m long LED light board.

Theory of 18000 points per hour. The actual production speed of about 9000 points per hour,

suitable for small and medium batch production and with high-speed placement machine.

MC Type
YV100X
PCB size
L460 x W445mm (Max.), L50 x W50mm (Min.)or L460 x W335mm
Accuracy  +-0.1mm(Chips)  +-0.08mm(QFP)
Mounting Speed
0.198sec/chips,18000CPH
1.7sec/QFP
Mounting angle
+-180°, per0.01°
Space for cassettes
100 of 8mmTape,
and 80 trays with YTF. (Option)
Available feeders
8-56mmTapes, Sticks, Bulks, Trays
Available Components
From 0.6mmX0.3mm to 32mmX100mm,
Maximum component height 6.5mm
Maximum mounting data
10000 mounting line/ 1 production data,
Maximum 500 production data in the hard disk.
Machine size： L1,655XW1,408XH1,850mm
Machine weight：1,450kg
